STMicroelectronics, Innoscience Sign GaN Technology Agreement

STMicroelectronics and Innoscience, a world leader in 8” GaN-on-Si (gallium nitride on silicon) high-performance low-cost manufacturing, announce the agreement on GaN technology development and manufacturing, leveraging the strengths of each company to enhance GaN power solutions and supply chain resilience.

The companies have agreed on a joint development initiative on GaN power technology, to advance the promising future of GaN power for consumer electronics, datacenters, automotive and industrial power systems and many more applications in the coming years.

In addition, the agreement allows Innoscience to utilize ST’s front-end manufacturing capacity outside China for its GaN wafers, while ST can leverage Innoscience’s front-end manufacturing capacity in China for its own GaN wafers.

“ST and Innoscience are both integrated device manufacturers, and with this agreement we will leverage this model to the benefit of our customers globally,” said Marco Cassis, president, Analog, Power & Discrete, MEMS and Sensors of STMicroelectronics. “First, ST will be accelerating its roadmap in GaN power technology to complement its silicon and silicon carbide offering. Second, ST will be able to leverage a flexible manufacturing model to serve customers globally.”

“GaN technology is essential to improve electronics, creating smaller and more efficient systems which save electric power, lower cost, and reduce CO2 emissions,” Dr. Weiwei Luo, chairman and founder of Innoscience, stated. “Innoscience pioneered mass production of 8-inch GaN technology and has shipped over 1 billion GaN devices into multiple markets, and we are very excited to move into strategic collaboration with ST. The joint collaboration between ST and Innoscience will further expand and accelerate the adoption of GaN technology. Together the teams at Innoscience and ST will develop the next generations of GaN technology.”

GaN power devices leverage fundamental material properties that enable new standards of system performance in power conversion, motion control, and actuation, offering significantly lower losses, which allows for enhanced efficiency, smaller size, and lighter weight, thus reducing the overall solution cost and carbon footprint. These devices are rapidly being adopted in consumer electronics, data center and industrial power supplies, and solar inverters, and are being actively designed into next-generation EV powertrains due to their substantial size and weight reduction benefits.
