Holst Centre Shows New Protective Barrier for Organic Electronics that is Foldable

Researchers from Holst Centre have solved a major challenge in creating large-area displays for portable devices, demonstrating a new protective barrier for organic electronics that is foldable and allows high-temperature processing of display backplanes on top.

OLEDs are extremely sensitive to humidity, and the flexible substrates needed for foldable displays don’t provide enough protection against moisture. Flexible displays need moisture-proof protective barrier layers above and below the sensitive OLED materials. However, the materials used in these barriers are quite brittle, limiting how much resulting displays can be bent and hampering the development of foldable displays.

Holst Centre’s new optimized barrier makes foldable displays possible. It comprises an organic layer sandwiched between two layers of silicon nitride (SiN) – a standard barrier layer material. By optimizing the design of this stack, Holst Centre’s scientists have been able to control its mechanical properties and create a much more flexible barrier that ensures the neutral stress line during bending is close to the active layers of the display to prevent mechanical and electrical degradation. The organic material also helps prevent moisture penetration through pinholes by ensuring very slow lateral spreading of water between the SiN layers.

Crucially, the particular organic material used is stable up to 400°C and can be applied by slot-die coating. Moreover, it means the barrier can withstand the high temperatures used in display production processes, making it suitable for the bottom protective layers.

“Foldable displays are a hot topic right now, with many people claiming to demonstrate them. But the term is applied quite loosely, and very few – if any – of these demonstrators achieve the bending radii of 2 mm or less needed to be truly foldable. Our optimized multilayer barrier now makes foldable OLED displays possible. Not only does it enable very small bending radii, it is compatible with standard display production processes and provides excellent protection against water and stress for long-lasting displays,” said Hylke Akkerman, program manager at Holst Centre.

OLED demonstrators using the new barrier have achieved 1000 hours with no blackspots in accelerated lifetime testing, even after ten thousand cycles of folding with a bending radius of 0.5 mm. This represents an operational lifetime of several years. With earlier versions of the barrier already deployed in its own Gen 1 pilot production line, Holst Centre is currently transferring this latest barrier to a production at a partner’s facility.
