Bobst Unveils 20SEVEN CI Flexo Press

Bobst has launched its new 20SEVEN flexo press, which deliverd ECG solutions for a variety of printing technologies and applications.

“Bobst has been an advocate of the ECG concept since 2013, with the now well-established Revo 7-color Digital Flexo technology developed with leading industry suppliers for narrow and mid-web inline flexo presses,” said Federico d’Annunzio, strategic products marketing director, Bobst Business Unit Web-fed. “In 2017, Bobst introduced the THQ FlexoCloud, a fixed color palette solution for corrugated board post print applications. Today, we are tackling wide-web CI flexo printing with the 20SEVEN, which offers features that have been specifically developed to deliver best results with ECG printing.”

What are the key factors, market trends and ECG specific requirements considered in the development of the new machine? “High-quality imaging should be consistently repeatable run after run, at high speed, with both solvent-based and water-based inks. The ECG implementation system should be open for use with different printing plates, inks or industry suppliers. The experience of our customers who have implemented the ECG project on other Bobst CI flexo presses like the 20SIX has obviously been invaluable in developing the solution,” says Dieter Betzmeier, R&D director, Bobst Bielefeld. “From a technical point of view, we addressed the rigidity of the print deck, the ink flow, the drying and the stability of the register.”

Ink is a factor that can have a major bearing on process consistency. The Bobst smartFLO system does away with the variables that can have an impact on the uniformity of ink consistency and flow. These include ink variations owing to environmental factors such as temperature and light, change of viscosity due to peaks in the flow from the ink bucket to the substrate and inconsistent ink metering as a result of the ink pumps.

Another fundamental aspect is press drying efficiency. This is even more pronounced with water-based ink printing, which is on the increase in flexible packaging applications. The new FSM (Full Surface Matrix) dryer provides a higher efficiency compared with one-slot drying systems as the blast of air is applied to the substrate over the whole surface of the dryer through hundreds of small jets.

In terms of repeatability, the Bobst CI flexo presses rely on the smartGPS system. The Bobst offline registration and pressure setting system, in addition to its well-known performance in minimum waste at start-up and job changeovers, are also instrumental in increasing the lifetime of high resolution plates by printing the real format, avoiding any distortion of dots.
